Type: LDT series Straw Bales Shredder
Power(kw): 15 – 160
Capacity(t/h): 5 – 60
Application: Used for bundled straw, baled straw, bundled grass,various shapes baled and so on.
Heavy rotary knife with high crushing efficiency. The knives are all made of alloy steel, sturdy and durable, with a long service life.
Thick frame plate can resist high torque, which is very sturdy.
Adopting microcomputer (PLC) automatic control, and having such control functions as start, stop, reverse and overload automatic reverse.
The equipment has the characteristics of low rotating speed, high torque, low noise and the dust achieving the environmental standards.
Easy adjustment, low maintenance cost, economic durability.
The thickness of the knives and the numbers of the claws can be changed according to different materials.
For different material properties, flexible choice of equipment knife roll, enhance the shredding effect.
The thickness and the number of blade can be changed according to different materials.When crushing hollow material, can be equipped with pressure device to increase production.
The thickness of the shredder blade is divided into 15mm, 20mm, 40mm, 50mm, 75mm, 100mm， can select the blade according to the particle size after crushing.
| Model | Main Shaft (pcs) | Blades Size (mm) | Blades (pcs) | Reducer (sets) | Motor Power (kw) | Main Shaft Speed (r/min) | Dimensions (mm) |
| LDT600 | 2 | Φ250*10 | 48 | 400*2 | 15*2 | 18-25 | 1450*870*2200 |
| 2 | Φ250*20 | 24 | 400*2 | 15*2 | 18-25 | 1450*870*2200 | |
| LDT800 | 2 | Φ250*20 | 32 | 400*2 | 30*2 | 18-25 | 2150*870*2200 |
| 2 | Φ250*30 | 18 | 650*2 | 30*2 | 18-25 | 3400*1250*2200 | |
| LDT1000 | 2 | Φ350*30 | 28 | 650*2 | 37*2 | 18-25 | 3400*1250*2200 |
| 2 | Φ350*40 | 20 | 750*2 | 37*2 | 18-25 | 4150*1250*2200 | |
| LDT1200 | 2 | Φ350*30 | 38 | 650*2 | 55*2 | 18-25 | 4150*1250*2200 |
| 2 | Φ350*40 | 28 | 750*2 | 55*2 | 18-25 | 4150*1250*2200 | |
| LDT1500 | 2 | Φ400*40 | 36 | 750*2 | 75*2 | 18-25 | 4150*1250*2200 |
| 2 | Φ400*50 | 28 | 850*2 | 75*2 | 18-25 | 4150*1250*2200 | |
| LDT2000 | 2 | Φ530*50 | 38 | 850*2 | 90*2 | 18-25 | 5250*1780*2200 |
| 2 | Φ600*60 | 32 | 850*2 | 90*2 | 18-25 | 5250*1780*2200 | |
| LDT2500 | 2 | Φ600*60 | 60 | 1000*2 | 110*2 | 18-25 | 7500*3200*3800 |
| 2 | Φ600*75 | 50 | 1000*2 | 110*2 | 18-25 | 7500*3200*3800 | |
| LDT3000 | 2 | Φ600*75 | 56 | 1200*2 | 132*2 | 18-25 | 8600*3500*4000 |
| 2 | Φ600*100 | 44 | 1200*2 | 132*2 | 18-25 | 8600*3500*4000 |
