Type: LDT series Metal Shredder
Power(kw): 15 – 160
Capacity(t/h): 5 – 60
Application: Used for waste car, motocycle, bicycle, metal barrels, aluminum, metal tube, color steel tile, etc.
The main function of the metal shredder is to crush the large size and inconvenient transportation of large diameter barrel metal material by shearing each other through the shear of the metal shredder.
The large metal shredder not only improves the production capacity and shredding efficiency, also enlarges the application range. Our company production of large metal shredder is a kind of advanced finely shredding machine, this series of large metal shredder on the basis of absorbing the advantages of many kinds of shredder, also full use theories of impact, shear, impact each other, grinding attentively. Large metal shredder equipment produced by Luoyang Luodate have caught up with other company in the same industry.
For different material properties, flexible choice of equipment knife roll, enhance the shredding effect.
The thickness and the number of blade can be changed according to different materials.When crushing hollow material, can be equipped with pressure device to increase production.
The thickness of the shredder blade is divided into 15mm, 20mm, 40mm, 50mm, 75mm, 100mm， can select the blade according to the particle size after crushing.
| Model | Main Shaft (pcs) | Blades Size (mm) | Blades (pcs) | Reducer (sets) | Motor Power (kw) | Main Shaft Speed (r/min) | Dimensions (mm) |
| LDT600 | 2 | Φ250*10 | 48 | 400*2 | 15*2 | 18-25 | 1450*870*2200 |
| 2 | Φ250*20 | 24 | 400*2 | 15*2 | 18-25 | 1450*870*2200 | |
| LDT800 | 2 | Φ250*20 | 32 | 400*2 | 30*2 | 18-25 | 2150*870*2200 |
| 2 | Φ250*30 | 18 | 650*2 | 30*2 | 18-25 | 3400*1250*2200 | |
| LDT1000 | 2 | Φ350*30 | 28 | 650*2 | 37*2 | 18-25 | 3400*1250*2200 |
| 2 | Φ350*40 | 20 | 750*2 | 37*2 | 18-25 | 4150*1250*2200 | |
| LDT1200 | 2 | Φ350*30 | 38 | 650*2 | 55*2 | 18-25 | 4150*1250*2200 |
| 2 | Φ350*40 | 28 | 750*2 | 55*2 | 18-25 | 4150*1250*2200 | |
| LDT1500 | 2 | Φ400*40 | 36 | 750*2 | 75*2 | 18-25 | 4150*1250*2200 |
| 2 | Φ400*50 | 28 | 850*2 | 75*2 | 18-25 | 4150*1250*2200 | |
| LDT2000 | 2 | Φ530*50 | 38 | 850*2 | 90*2 | 18-25 | 5250*1780*2200 |
| 2 | Φ600*60 | 32 | 850*2 | 90*2 | 18-25 | 5250*1780*2200 | |
| LDT2500 | 2 | Φ600*60 | 60 | 1000*2 | 110*2 | 18-25 | 7500*3200*3800 |
| 2 | Φ600*75 | 50 | 1000*2 | 110*2 | 18-25 | 7500*3200*3800 | |
| LDT3000 | 2 | Φ600*75 | 56 | 1200*2 | 132*2 | 18-25 | 8600*3500*4000 |
| 2 | Φ600*100 | 44 | 1200*2 | 132*2 | 18-25 | 8600*3500*4000 |
